Heat Exchanger WSH-113
Heat Capacity (kW)
1432
Volume of the cavity (L)
13,4
Working pressure (MPa)
1,0
Weight (kg)
71
Surface area (m²)
3,09
Connection
Flanged DN 65 mm, PN 1.0 MPa, DIN 2576
Inter-tube volume (L)
21,9
Heat carrier flow rate (kg/h)
2557
Coolant flow rate (kg/h)
24633
11 000 грн
11 000 грн
- Video review
- Description
- Specification
The WSH-113 heat exchanger from LLC "KYIVPROMTECHSERVICE" is designed for efficient heat exchange in industrial, commercial, and engineering systems. The product is manufactured according to proprietary technical specifications (TU) and complies with international ISO standards, ensuring high quality, reliability, and durability.
Advantages:
- High heat exchange efficiency
- Resistance to high temperatures and pressure
- Reliable welded construction
- Custom manufacturing with parameter adjustment options
- Compliance with international standards
Applications:
- Heating and ventilation systems
- Industrial heat exchange equipment
- Technological processes in the food, chemical, and other industries
- Heat recovery and energy-efficient solutions
Contact us for consultation or to place an order!
| Heat Capacity (kW): | 1432 |
| Volume of the cavity (L): | 13,4 |
| Working pressure (MPa): | 1,0 |
| Weight (kg): | 71 |
| Surface area (m²): | 3,09 |
| Connection: | Flanged DN 65 mm, PN 1.0 MPa, DIN 2576 |
| Inter-tube volume (L): | 21,9 |
| Heat carrier flow rate (kg/h): | 2557 |
| Coolant flow rate (kg/h): | 24633 |
