Energy section KNVE-216
Heat Capacity (kW)
1000
Airflow (m³/h)
62000
Length (mm)
2200
Height (mm)
1260
Width (mm)
348
Number of rows
2
Surface area (m²)
200
Type of energy carrier
Steam
Material
Structural steel
Ribbing
Aluminum AD0
Working pressure (MPa)
1,2
Connection
Weldable
Weight (kg)
410
86000 грн
86000 грн
- Video review
- Description
- Specification
The KNVE-216 Energy Section, manufactured by LLC "KYIVPROMTECHSERVICE", complies with the requirements of ISO 9001 and other industry standards, ensuring its high quality, reliability, and safety. It is made of durable, wear-resistant materials, providing long-term operation even under increased loads.
Main Characteristics:
- Compliance with standards: Manufactured according to TU and international standards ISO 9001, ISO 14001, ISO 45001
- Materials: High-strength steel, anti-corrosion coating, heat-resistant components
- Resistance to external factors: High mechanical strength, heat resistance, electrical insulation properties
- Purpose: Used in industrial, energy, and engineering facilities
- Quality assurance: Production control at all stages
Advantages:
- Durability – the use of certified materials extends the product’s service life
- Safety and efficiency – meets the requirements of technical regulations and international standards
- Custom manufacturing options – adaptation to specific customer needs
- High performance – ensures stable and uninterrupted operation of energy systems
Contact us for consultation and orders.
| Heat Capacity (kW): | 1000 |
| Airflow (m³/h): | 62000 |
| Length (mm): | 2200 |
| Height (mm): | 1260 |
| Width (mm): | 348 |
| Number of rows: | 2 |
| Surface area (m²): | 200 |
| Type of energy carrier: | Steam |
| Material: | Structural steel |
| Ribbing: | Aluminum AD0 |
| Working pressure (MPa): | 1,2 |
| Connection: | Weldable |
| Weight (kg): | 410 |
